Vocia is a Digital Paging Platform, which provides distributed digital audio, signal processing, and control.
Vocia is a networked, decentralized paging system, which is easy to configure & program.
Vocia allows the system designer to quickly & accurately define the exact paging system required for each job.
Vocia is software programmable, easily expandable, and remotely controllable.
Vocia utilizes both CobraNet® and Ethernet for enhanced system networking and control.
Vocia is a completely customizable, yet cost-effective, solution for paging system design.
Vocia is covered by a five-year warranty (MS-1e and TTS-2 have three year warranty ).
Filters: HPF, LPF, high shelving, low shelving, all-pass, band pass, notch.
Crossovers: 2-way, 3-way, 4-way, Butterworth, Bessel, Linkwitz-Riley.
Dynamics: Compressor/limiters, duckers, ambient noise compensators.
Delays: 0 to 2700 ms. For the VA-4300CV and the VA-8150CV 32,000ms.
Controls: gain, level, event scheduling, ducking, VoIP paging, POTS paging, GPIO.
Meters: RMS.
24-bit A/D & D/A converters.
Paging Stations powered via Power-over-Ethernet (PoE).
Hardware devices to comprise an entire Paging System from paging microphone to amplifier.
Wall mount or desk mount paging stations.
Fluid routing of any input to any output.
Ethernet and CobraNet communications for software control and configuration.
Rotary switches for device identification.
Multiple analog I/O configurations possible.
VI-6 has Mic/Line inputs on terminal block and RCA connectors.
Alarm reporting from each device to MS-1e or PC running Vocia software.
MS-1e E-mail reporting and notification of events.
WR-1 Wall plate device for Zone BGM user control.
Control Inputs and Outputs.
Works with standard Ethernet switches.
Configuration settings stored in flash memory in every device.
Preamble storage in Paging Station memory.
PIN security for Paging Stations.
MS-1e allows Recorded announcement storage and playback and the ability for User recorded and Recorded message VoIP Paging.
TTS-1nce and TTS-2 allow realistic Text-to-Speech engine with web based interface in multiple languages and integration with Rauland 4 and 5 nurse call systems.
Life Safety Interface for integration with fire alarm systems.
CE marked and RoHS compliant.
Plug-and-Play Device Replacement when MS-1e or PC running Vocia software is Online.
ANC-1 allows Automatic, adaptive volume adjustment based on ambient noise sensing and processing.
GPIO-1 provides for sixteen general purpose inputs and sixteen outputs.
VI-8 has analog (Mic/Line) or CobraNet inputs for live emergency and non-emergency paging
VoIP-1 facilitates a direct connection from SIP based VoIP extensions for live paging and control
POTS-1 facilitates a direct connection from a standard POTS or PBX system for live paging and control
Event Scheduling via MS-1.
Network Time (NTP) Server support.
Windows® Operating System required
Auto discovery of devices via CobraNet.
Simple tree view based layout architecture.
Control any Zone via connected software interface.
Manage security via PIN, Software and System Login.
Real time Alarm and device status monitoring.
Easy to use Audio File Manager with Normalization for importing announcements, Preambles and VoIP Prompts.
Firmware update all connected devices at the same time.
Priority Levels for regular and emergency paging.
Export ZIP file for support.
System log stored on system when an MS-1e is included in the system or via a PC running Vocia software.
The ability to extract configuration from a configured system.
Four different types of system report in PDF, Word or Excel format.
